Application:
It is widely used in dairy industry, food industry, pharmacy, chemical industry, beverage and other industrial sectors, as heating, cooling, heat preservation, anti-corrosive, anti-corrosive, strong production capacity, Cooling,insulation, sterilization treatment or storage of slurry must be stainless steel mixing tanks, especially for pasteurization of milk and
insulation, ice cream production line is the necessary equipment.
Material: SS304 / 316L;
Capacity: 50-5000L (customized is accepted);
Configuration with agitator and/or homogenizer;
Jacket: single layer, double jacket, three-layer
Thickness: 2mm, 3mm, 4mm, 5mm, 6mm, 8mm etc. (design according to pressure);
Head: open cover, seal with manhole/handhole etc.;
Shape: cylinder or cone, conical /flat/elliptical bottom with discharge.
Heat Method: gas, steam, electricity;
Parameters：
Capacity Heating power (KW) Inner diameter(mm) Jacket diameter (mm) Speed(rpm) power(KW)
HD-50L 4*2 400 600 23-600/2800 0.75kw/2.2kw
HD-100L 6*2 500 700 23-600/2800 1.1kw/3.0kw
HD-300L 6*4 800 1000 23-600/2800 2.2kw/4.0kw
HD-500L 9*4 900 1100 23-600/2800 3.0kw/7.5kw
HD-1000L 12*4 1200 1400 23-600/2800 4.0kw/11kw
HD-2000L 15*5 1400 1600 23-600/2800 4.0kw/22kw
HD-3000L 15*6 1600 1800 23-600/2800 5.5kw/30kw
